Comparative Study of MRI Biomarkers in the Substantia Nigra to Discriminate Idiopathic Parkinson Disease

N. Pyatigorskaya; B. Magnin; M. Mongin; L. Yahia-Cherif; R. Valabregue; D. Arnaldi; C. Ewenczyk; C. Poupon; M. Vidailhet; S. Lehéricy

doi:10.3174/ajnr.A5702

Abstract

BACKGROUND AND PURPOSE: Several new MR imaging techniques have shown promising results in patients with Parkinson disease; however, the comparative diagnostic values of these measures at the individual level remain unclear. Our aim was to compare the diagnostic value of MR imaging biomarkers of substantia nigra damage for distinguishing patients with Parkinson disease from healthy volunteers.

MATERIALS AND METHODS: Thirty-six patients and 20 healthy volunteers were prospectively included. The MR imaging protocol at 3T included 3D T2-weighted and T1-weighted neuromelanin-sensitive images, diffusion tensor images, and R2* mapping. T2* high-resolution images were also acquired at 7T to evaluate the dorsal nigral hyperintensity sign. Quantitative analysis was performed using ROIs in the substantia nigra drawn manually around the area of high signal intensity on neuromelanin-sensitive images and T2-weighted images. Visual analysis of the substantia nigra neuromelanin-sensitive signal intensity and the dorsolateral nigral hyperintensity on T2* images was performed.

RESULTS: There was a significant decrease in the neuromelanin-sensitive volume and signal intensity in patients with Parkinson disease. There was also a significant decrease in fractional anisotropy and an increase in mean, axial, and radial diffusivity in the neuromelanin-sensitive substantia nigra at 3T and a decrease in substantia nigra volume on T2* images. The combination of substantia nigra volume, signal intensity, and fractional anisotropy in the neuromelanin-sensitive substantia nigra allowed excellent diagnostic accuracy (0.93). Visual assessment of both substantia nigra dorsolateral hyperintensity and neuromelanin-sensitive images had good diagnostic accuracy (0.91 and 0.86, respectively).

CONCLUSIONS: The combination of neuromelanin signal and volume changes with fractional anisotropy measurements in the substantia nigra showed excellent diagnostic accuracy. Moreover, the high diagnostic accuracy of visual assessment of substantia nigra changes using dorsolateral hyperintensity analysis or neuromelanin-sensitive signal changes indicates that these techniques are promising for clinical practice.

ABBREVIATIONS:

AD: axial diffusivity
DNH: dorsal nigral hyperintensity
FA: fractional anisotropy
ICC: intraclass correlation coefficient
HV: healthy volunteer
MD: mean diffusivity
NM: neuromelanin
PD: Parkinson disease
RD: radial diffusivity
ROC: receiver operating characteristic
SN: substantia nigra
UPDRS: Unified Parkinson's Disease Rating Scale

In Parkinson disease (PD), several MR imaging biomarkers have been successfully used to detect neurodegenerative changes in the substantia nigra (SN).^1⇓–3 By means of DTI, decreased fractional anisotropy (FA)^2,3 and modifications in axial (AD),⁴ radial (RD),² or mean (MD) diffusivity⁵ have been reported in the SN with some variability across studies.⁵ In addition, increased iron content in the SN of patients with PD has been shown by R2* relaxometry^2,3 or susceptibility imaging.⁶

In PD, dopaminergic neuronal loss occurs in the SN pars compacta,¹ and methods for specifically analyzing this region are of particular interest. Neuromelanin (NM), a by-product of dopamine that accumulates in dopaminergic neurons, has high signal intensity on T1-weighted spin-echo images due to its paramagnetic properties,^7,8 and several studies have shown reduced NM signal or volume in the SN in PD.^9,10 Because NM accumulates in the substantia nigra pars compacta, NM MR imaging is a promising technique in PD.¹¹

Histologic studies in PD have shown that depletion of dopaminergic neurons is most pronounced in the caudal and lateral regions of the substantia nigra pars compacta, called nigrosome-1.¹² Signal changes in this area have been shown in PD using high-resolution T2*-weighted or susceptibility-weighted imaging at both 7T¹³ and 3T.¹⁴ The normal aspect of this dorsolateral region is a hyperintense, ovoid area within the hypointense SN. However, this hyperintensity, referred to as dorsal nigral hyperintensity (DNH), is lost in PD.^13,14 Both NM-sensitive and DNH imaging may be useful in clinical practice.^13⇓–15

Although these MR imaging techniques have shown good results for differentiating patients from controls either separately^16,17 or by using a combination of diffusion and iron imaging,³ the comparative diagnostic values of these measures at the individual level remain unclear and have not been tested yet. The aims of our study were to compare the diagnostic efficacy of DTI, R2*, NM-sensitive imaging, and DNH and to determine the best combination of measures to detect specific SN alterations in PD.

Materials and Methods

Subjects

Thirty-six patients were prospectively recruited from the Movement Disorders Clinic at Pitié-Salpêtrière Hospital between April 2010 and September 2012. The inclusion criteria were clinical diagnosis of idiopathic PD (according to UK Parkinson's Disease Brain Bank criteria), no or minimal cognitive disturbances (Mini-Mental State Examination score = >24), age younger than 75 years, and complete MR imaging examination on both 3T and 7T scanners. Patients were compared with 20 healthy volunteers (HVs) with no medical history of any neurologic disorders, having normal clinical examination findings, and matched for age and sex. All subjects gave written informed consent, and the local ethics committee approved the study (CPP Paris VI, RCB: 2009-A00922–55).

Clinical and Neurologic Examination

Motor disability was evaluated using the Unified Parkinson's Disease Rating Scale, Part III (UPDRS-III) in the “ON” (peak effect of dopaminergic treatment) and “OFF” (12-hour dopaminergic treatment withdrawal) conditions and the Hoehn and Yahr staging.

MR Imaging Acquisition

Acquisitions were performed using 3T Trio and 7T Magnetom (Siemens, Erlangen, Germany) scanners and a 12-channel (3T) or an 8-channel (7T) head coil for signal reception for all subjects. The 3T protocol included high-resolution anatomic 3D T1WI, T2WI, NM-sensitive spin-echo T1WI, DTI, and R2* mapping. The 3D T1WI was acquired using a sagittal MPRAGE acquisition (TI, 900 ms; TR/TE/flip angle, 2300 ms/4.18 ms/9°; 1 average; voxel size, 1 × 1 × 1 mm³). NM-sensitive images were acquired using 2D axial turbo spin-echo T1WI (TR/TE/flip angle, 900 ms/15 ms/180°; 3 averages; voxel size, 0.4 × 0.4 × 3 mm³). DTI parameters were TR/TE/flip angle, 14,000 ms/101 ms/90°; b-value,1500 s/mm²; voxel size, 1.7 × 1.7 × 1.7 mm³; 60 diffusion gradient directions. R2* mapping was computed using a gradient echo-planar imaging sequence with 6 TEs (range, 24–94 ms); TR/flip angle, 9000 ms/90°; voxel size, 2 × 2 × 2 mm³. The 7T image acquisition included 3D T2*WI coronal images with TR/TE/flip angle, 2180 ms/29.9 ms/65°; FOV, 192 mm²; voxel size, 0.5 × 0.5 × 0.5 mm³; 40 slices.

Image Analysis

ROIs.

SN segmentations at 3T were performed by 2 examiners using FreeSurfer software (http://surfer.nmr.mgh.harvard.edu) and at 7T by 1 trained examiner using ITK-SNAP 1.6 software (www.itksnap.org).¹⁸ To evaluate the accuracy of segmentation at 7T, a second examiner performed segmentations in the last 10 selected subjects. The concordance between the segmentations was good (Dice similarity coefficient = 0.87).

For NM images, contours of the SN were manually drawn around the area of high signal intensity twice by each blinded rater. The concordance between the segmentations was good (Dice similarity coefficient = 0.8). This 3T NM ROI primarily corresponded to the substantia nigra pars compacta.¹⁹ For 3T T2WI and 7T T2*WI, the SN was defined as the area of hypointensity ventral to the red nucleus and dorsal to the cerebral peduncle, primarily corresponding to the SN pars reticulata (Fig 1).¹⁹ The SN was separated from the subthalamic nucleus by a small notch on its lateral and anterior borders. The subthalamic nucleus was also segmented to avoid any error. All examiners were blinded to the subject's clinical status.

Fig 1.

Segmentation of ROIs. Axial brain stem slices in a healthy volunteer (A) and a patient with Parkinson disease (B) show reduction of the neuromelanin signal intensity in the substantia nigra of the patient. Axial T2*WI 7T slices show dorsal nigral hyperintensity in a HV (C), which is absent in the patient with PD (D). T2WI axial (E) and coronal (F) images of the SN in a HV show T2-based segmentation of the SN.

Quantitative Analysis.

The volumes of NM-based ROIs were calculated using in-house Matlab algorithms (MathWorks, Natick, Massachusetts). The signal ratio was calculated by normalizing the mean signal of the SN in each slice to the signal in the background region, which was manually traced, including the tegmentum and superior cerebellar peduncles, as previously described.⁹ The interrater agreement was calculated, and the results were averaged across the raters and segmentations. DTI and R2* measures in the SN were calculated using both 3T NM and 3T T2WI ROIs. The DTI, NM-sensitive, and T2WI were coregistered to the 3D T1WI volume using the SPM coregister function (http://www.fil.ion.ucl.ac.uk/spm/software/spm12). DTI preprocessing was performed using the FMRIB Software Library, Version 5.0 (FSL; http://www.fmrib.ox.ac.uk/fsl). Motion and eddy currents were corrected using the eddy_correct function in FSL. Echo-planar deformations were corrected using field maps. FA and diffusivity maps were computed with the DTIFit (http://fsl.fmrib.ox.ac.uk/fsl/fsl-4.1.9/fdt/fdt_dtifit.html) function for the entire volume. Noise filtering was applied. The mean value of each measure was computed in the SN ROIs. For R2* calculation, all images were realigned, normalized, and coregistered. R2* maps were calculated by fitting the data to the logarithmic signal decay over all 6 TEs. The mean R2* value was calculated over each ROI.

Blind Visual Analysis.

Two raters visually analyzed the SN signal intensity in the NM-sensitive images and the presence of DNH. To assess intra- and interobserver reproducibility, each reading was performed twice at a 4-week interval. There was no time limit for visual evaluations. For conflicting cases, agreement between raters was reached.

NM-sensitive images were classified according to a 2-point scale, as follows: 1, a normal aspect of the SN with high signal intensity bilaterally and no volume loss, indicating a healthy subject; or 2, an abnormal aspect with reduced signal or volume of the SN unilaterally or bilaterally, indicating a subject with pathology.

The DNH sign was categorized using a 2-point scale: 1, normal; or 2, pathologic. We used 2 classification methods: 1) Unilateral or bilateral absence of DNH was considered pathologic,²⁰ and 2) only bilateral DNH absence was considered pathologic.¹⁴

Statistical Analysis

Statistical analysis was performed using Matlab (MathWorks). Intra- and interrater intraclass correlations (ICCs) were calculated for quantitative data. Group differences were determined using a 1-way MANOVA. Preliminary assumptions of homogeneity of variance were assessed by the Levene test. Between-group differences were estimated using Pillai's Trace (http://www.statisticshowto.com/pillais-trace/). Follow-up univariate ANOVA was performed for measures; differences were considered significant at P < .05. The diagnostic threshold value was calculated using receiver operating characteristic (ROC) curve analysis, and the sensitivity and specificity of cutoff points were estimated using the Youden index. The inter- and intrarater agreement for qualitative measurements was estimated using the Cohen κ coefficient. The sensitivity, specificity, positive predictive value, and negative predictive value were calculated. Diagnostic accuracy between 0.9 and 1 was considered “excellent”; between 0.80 and 0.90, “good”; and between 0.70 and 0.80, “fair.” The best combination of variables for disease prediction was determined using a logistic regression model. Associations between clinical measures and MR imaging measurements were studied regarding PD. Age and sex were controlled by partial correlations followed by a multiple comparisons permutation approach. An approximate multivariate permutation test was conducted, and the sampling distribution was built to calculate the corrected P value as the proportion of the observed significant correlation coefficient value.²¹

Results

Population Characterization

Thirty-six patients with PD (mean age, 60.1 ± 10.1 years; 27 men) and 20 HVs (mean age, 60.8 ± 8.3 years; 12 men, P = .2) were analyzed. The mean duration of disease was 9.1 ± 3.6 years, the mean UPDRS-III-ON was 14.8 ± 8.8, the mean UPDRS-III-OFF was 28.3 ± 9.6, and the mean Hoehn and Yahr scale score was 1.9 ± 0.6. The mean UPDRS-OFF score for the HV group was 0.8 ± 1.0. The mean Mini-Mental State Examination score was 27.9 ± 1.8 in PD and 28.8 ± 1.1 in HV, P = .03. The mean Mattis score was 137 ± 5.2 in PD and 140 ± 2.6 in HV, P = .009.

Quantitative MR Imaging Data Analysis

MANOVA preliminary assumptions revealed homogeneity of variance (Levene test). The between-group differences for all measures in the SN were statistically significant [F(12,43) = 5.387, P < .001; partial η2 = 0.601, Pillai's Trace].

The analysis was followed up by univariate ANOVAs for each SN metric.

NM-Sensitive Volume.

The average NM-sensitive volume was lower in patients with PD than in HVs (F = 24.85, P < .001, Table 1 and Fig 2A).

View this table:

Table 1:

Quantitative measurements in the SN^{^a}

Fig 2.

Boxplot of the 3T NM SN volume (cubic millimeters) (A) and signal intensity ratio (B) (calculated by normalizing the mean signal of the SN in each slice to the signal in the background region), the 3T NM FA (C), and the 7T T2*WI SN volume (D) shows a reduction in all measures in patients with PD compared with HVs.

ROC analysis showed good discrimination between patients with PD and HVs (Fig 3A and Table 2). Interrater (ICC = 0.86; 95% CI, 0.78–0.91; P < .001) and intrarater (reader 1: ICC = 0.81; 95% CI, 0.65–0.87; P < .001; reader 2: ICC = 0.84; 95% CI, 0.75–0.90; P < .001) agreements were good.

Fig 3.

Receiver operating characteristic curves of the 3T NM volume, the 3T NM signal intensity ratio, the 3T NM FA, the 7T T2* volume (A), and the combination of the first 3 biomarkers for differentiating patients with PD from HVs (B).

View this table:

Table 2:

Diagnostic accuracy of quantitative and qualitative (visual) assessments

NM-Sensitive Signal.

The average NM-sensitive signal in patients with PD was lower than in that in HVs (F = 27.39, P < .001; Table 1 and Fig 2B). ROC analysis showed good discrimination between patients with PD and HVs (Fig 3A and Table 2). Interrater agreement was excellent (ICC = 0.91; 95% CI, 0.86–0.94; P < .001), and intrarater agreement was good (reader 1: ICC = 0.8; 95% CI, 0.69–0.87; reader 2: ICC = 0.86; 95% CI, 0.77,0.91; P < .001).

DTI Parameters.

For the DTI parameters, in the 3T NM SN ROI, patients with PD showed an increased average MD (F = 11.47, P = .001), AD (F = 11.23, P = .001), and RD (F = 11.1, P = .002) and a reduced FA (F = 4.46, P = .04). In the 3D T2WI SN ROI, an increase in RD (F = 6.55, P = .01) and MD (F = 5.23, P = .03) was observed, with no significant differences in FA or AD (Table 1 and Fig 2C). ROC analysis showed fair discrimination between patients with PD and HVs for all parameters (Table 2 and Fig 3A).

R2*.

There was no difference between patients with PD and HVs for R2* in either 3T NM or 3T T2WI ROIs.

7T T2*WI SN Volume.

Patients with PD exhibited lower 7T T2*WI SN volumes than the HV group (F = 4.06, P = .05) (Table 1 and Fig 2D). ROC analysis showed good discrimination between patients with PD and HVs (Fig 3A and Table 2), with a higher area under the curve for the NM-sensitive volume than for the 7T T2* volume. Interrater agreement for volume measurements was excellent (ICC = 0.9927; 95% CI, 0.9864–0.9961).

Best Variable Combinations.

A logistic regression model was used to determine the best variable combinations optimizing disease prediction. The logistic regression model was statistically significant [χ²(77) = 47.66, P < .001], explaining 78% (Nagelkerke R²) of the variance and correctly classifying 93% of the cases. Among predictor variables, 3 were statistically significant (signal, volume, and FA in the 3T NM ROI), and the combination of these variables improved sensitivity (91.7%), specificity (95%), and the area under the curve (95.6; 95% CI, 0.903–1). While we considered only the combination of the signal and volume in the 3T NM ROI, 89% of cases were correctly classified (area under the curve = 0.89; 95% CI, 0.8–0.98).

Qualitative Visual Analysis

NM-Sensitive Images.

The 2 raters discriminated the patients with PD and the HV group with good accuracy (Table 2). There was strong intrarater agreement for rater 1 (Cohen κ = 0.823; 95% CI, 0.674–0.972; P < .001) and rater 2 (κ = 0.830; 95% CI, 0.688–0.971; P < .001). Good interrater agreement was also found (κ = 0.815; 95% CI, 0.632–0.897; P < .001).

7T T2-weighted Images.

The 2 raters discriminated between the PD and HV subjects with good accuracy by both methods 1 and 2 (Table 2). There was good intrarater (κ = 0.834; 95% CI, 0.806–0.862; P < .001) and interrater (κ = 0.834; 95% CI, 0.806–0.862; P < .001) agreement.

Correlation between MR Imaging Data and Clinical Changes

For the 3T NM ROI, RD and MD in both hemispheres correlated positively with the UPDRS-OFF score (RD: r = 0.4, P = .007; MD: r = 0.4, P = .009), whereas FA correlated negatively with disease duration for the 3T T2WI ROI (r = −0.37, P = .015). Regarding the 7T T2*WI ROI, the SN volume bilaterally correlated positively with disease duration (r = 0.47, P = .018). No other significant correlations were found for the quantitative data.

Discussion

We found that NM imaging and DTI measures in the SN at 3T, as well as the SN volume using T2* images at 7T, were significantly different between patients with PD and HVs. The NM-based volume and signal had good diagnostic accuracy for separating patients with PD from HV subjects. DTI measures alone showed fair diagnostic accuracy, and their combination with NM imaging measures allowed excellent diagnostic performance. In addition, visual measures (DNH rating and NM visual assessment) also accurately distinguished patients with PD from the HV group. The sensitivity was better with the DNH rating, whereas the specificity was better with NM visual assessment.

Histologic studies have shown that neurodegeneration of the SN pars compacta is associated with a reduced number of pigmented neurons and a decrease in NM in the remaining neurons.^22,23 In line with these findings, NM-sensitive MR imaging showed a decrease in both the size and signal intensity of the SN area. These observations are in agreement with previous studies and confirmed that NM imaging is sensitive and specific for detecting nigrostriatal damage in PD.^9,10,17,24 The combination of volume and signal loss slightly increased the diagnostic accuracy.¹⁰

In our study, we found a significant increase in diffusivity and a decrease in FA in the 3T NM ROI in patients with PD, which is congruent with previous studies reporting FA reduction^2⇓–4 and increases in RD² and MD.⁵ These changes may be explained by cell loss– and microstructural damage–induced changes in cell morphology and density and the destruction of diffusion barriers.^24,25 In the 3T T2WI of the SN, we observed only slight modifications in RD and MD. This finding is in line with a recent article that reported PD-related DTI changes in the 3T NM ROI, corresponding to the substantia nigra pars compacta, but not in the 3T T2WI of the SN.¹⁹ The diagnostic accuracy of DTI for predicting PD varies across studies, from very low to very high,^4,26 and this was improved using free water models or kurtosis.^27,28 Some studies have shown that a combination of FA and R2* improves discrimination.^2,3 Here, we show that the diagnostic accuracy of DTI measures in the NM SN increased when combined with the NM signal and volume changes, though this was not the case for the 3T T2WI of the SN.

Quantitative measures are often challenging in clinical practice. First, DTI results largely differ among studies.^2,3,19 Second, SN volume on NM-sensitive images is variable across studies, ranging from 128 to 370 mm³ in HVs and from 96 to 215 mm³ in PD.^{7,10,15,17,24} These differences may be related to the scanner type, magnetic field strength, sequence parameters, image-processing methods, partial volume effect on 2D imaging, or ROI selection methods.²⁹ Within this context, qualitative measurements such as visual assessment of NM-sensitive images or DNH appear interesting.

Visual evaluation of NM signal changes was efficient for distinguishing patients from HVs, with a diagnostic accuracy comparable with that of quantitative measurements. Furthermore, visual analysis of SN signal changes was fast and did not require any postprocessing algorithm. Therefore, visual reading of NM-sensitive images might be of interest for the diagnosis of idiopathic PD in clinical practice, as suggested previously.¹⁵

We found excellent diagnostic accuracy of DNH loss at 7T for PD characterization, which is in agreement with previous studies at 7T^13,30 and 3T,^14,31 supporting the use of this technique in a clinical setting.³² Both approaches of visual analysis of DNH, based on the uni- or bilateral presence of DNH loss, resulted in equivalent overall correct classification.

Despite the good diagnostic accuracy of both DNH loss and NM-sensitive visual assessment, further comparison of these 2 sequences in clinical practice is needed.

There was no significant increase in R2* in PD; such increases have been observed in many, but not all,³³ previous studies.^2,3 A possible explanation for the lack of R2* changes is that R2* may decrease with disease progression.³⁴ Although iron accumulation leads to an increase in R2*, neuronal degeneration and gliosis induce a decrease in R2 relaxation rates within the tissue.³⁵

We found reduced T2*WI SN volume in PD at 7T, in line with previous studies.³⁶ Indeed, only 1 study at 7T reported an increase in SN volume in patients with PD.³⁰ These conflicting results may be due to differences in sequence parameters or patient populations. Further analysis is needed to clarify this issue.

In the 3T NM ROI, the UPDRS score correlated with MD and RD, and the disease duration correlated with FA and T2* volume. Overall, correlations between DTI measures and clinical variables are inconsistent across studies.^2,3,19 Longitudinal studies and the use of more complex diffusion models, such as free water diffusion, may help enhance our understanding of this relationship.²⁸ No correlation between the signal/volume loss and the UPDRS, disease duration, or Hoehn and Yahr scale was observed, in line with most previous studies.¹⁷ Nonetheless, 1 study did report a correlation with the Hoehn and Yahr scale,²⁴ and another, with the UPDRS.⁹ There were no correlations between NM changes and age or sex, consistent with some previous studies.^9,24 The lack of an age effect in our study may be explained by the relatively small age range of the subjects.

This study has several limitations. First, visual assessment is rater-dependent. However, both inter- and intrarater reproducibility were good. Manual segmentation is also dependent on the rater's reproducibility. However, Dice coefficients and the ICC were high (≥0.8), suggesting good accuracy of measurements. Second, the use of the 2D NM-sensitive sequences might have biased the volume measurements because of partial volume effects. Regardless, the results for NM-based volumes in the current study were comparable with those of previous studies.¹⁷ Moreover, ROC analysis allowed correct classification of the patients with PD and the HV group. Third, quantification of the NM signal in the SN required normalization with the background signal. To avoid the influence of potential inhomogeneity, the background ROI was large and based on several regions in each slice. Fourth, the mean disease duration in our sample was long. Accordingly, markers for PD neurodegeneration need to be tested in the early stages of PD. Finally, the DNH evaluation was performed at 7T, which is not used in clinical practice, though previous studies have shown that 7T results are similar to those of 3T.³¹

Conclusions

The combination of signal, volume, and FA measurements on NM-sensitive images allowed excellent diagnostic accuracy. Moreover, excellent accuracy of the visual assessment of DNH loss and NM-based signal changes in the SN confirmed that these techniques are promising for clinical practice. A follow-up study of signal intensity changes in the SN with disease progression will help determine whether this marker could be used to track the neurodegenerative process in neuroprotective trials.

Footnotes

Disclosures: Nadya Pyatigorskaya—RELATED: Grant: ANR Nucleipark, DHOS-Institut Nationale de la santé et de la recherche médical, France Parkinson, Ecole des NeuroSciences de Paris, Fondation pour la Recherche Médicale, and the Investissements d'Avenir (grant numbers IAIHU-06, Paris Institute of Neurosciences, ANR-11-INBS-0006), and Fondation d'Entreprise, Comments: noncommercial grants received by the institution for funding of the research*. Marie Mongin—RELATED: Grant: Fondation pour la Recherche Médicale. Marie Vidailhet—UNRELATED: Grant: Merz, Comments: unrestricted research grant*; Travel/Accommodations/Meeting Expenses Unrelated to activities listed: EAN, MDS, Comments: travel expenses for faculty at the MDS and EAN. Stéphane Lehéricy—RELATED: Grant: Investissements d'Aveni' (grant numbers ANR-10-IAIHU-06 and ANR-11-INBS-0006) and Fondation d'Entreprise, Agence nationale pour la recherche, DHOS-Institut Nationale de la santé et de la recherche médical, France Parkinson, Ecole des NeuroSciences de Paris, Fondation pour la Recherche Médicale, Comments: academic grants*; UNRELATED: Grants/Grants Pending: Servier, Pfizer, Biogen, Comments: research grants*; Payment for Lectures Including Service on Speakers Bureaus: Pileje, Lundbeck, Roche, Comments: lectures; Travel/Accommodations/Meeting Expenses Unrelated to activities listed: Siemens, GE Healthcare, Comments: visit to facilities. *Money paid to the institution.

Indicates open access to non-subscribers at www.ajnr.org

References

1.↵
2. Fearnley JM,
3. Lees AJ
. Ageing and Parkinson's disease: substantia nigra regional selectivity. Brain 1991;114(Pt 5):2283–301 doi:10.1093/brain/114.5.2283 pmid:1933245
CrossRef PubMed
2.↵
2. Du G,
3. Lewis MM,
4. Styner M, et al
. Combined R2* and diffusion tensor imaging changes in the substantia nigra in Parkinson's disease. Mov Disord 2011;26:1627–32 doi:10.1002/mds.23643 pmid:21618607
CrossRef PubMed
3.↵
2. Péran P,
3. Cherubini A,
4. Assogna F, et al
. Magnetic resonance imaging markers of Parkinson's disease nigrostriatal signature. Brain 2010;133:3423–33 doi:10.1093/brain/awq212 pmid:20736190
CrossRef PubMed
4.↵
2. Vaillancourt DE,
3. Spraker MB,
4. Prodoehl J, et al
. High-resolution diffusion tensor imaging in the substantia nigra of de novo Parkinson disease. Neurology 2009;72:1378–84 doi:10.1212/01.wnl.0000340982.01727.6e pmid:19129507
Abstract/FREE Full Text
5.↵
2. Schwarz ST,
3. Abaei M,
4. Gontu V, et al
. Diffusion tensor imaging of nigral degeneration in Parkinson's disease: a region-of-interest and voxel-based study at 3 T and systematic review with meta-analysis. Neuroimage Clin 2013;3:481–88 doi:10.1016/j.nicl.2013.10.006 pmid:24273730
CrossRef PubMed
6.↵
2. Barbosa JH,
3. Santos AC,
4. Tumas V, et al
. Quantifying brain iron deposition in patients with Parkinson's disease using quantitative susceptibility mapping, R2 and R2. Magn Reson Imaging 2015;33:559–65 doi:10.1016/j.mri.2015.02.021 pmid:25721997
CrossRef PubMed
7.↵
2. Sasaki M,
3. Shibata E,
4. Tohyama K, et al
. Neuromelanin magnetic resonance imaging of locus ceruleus and substantia nigra in Parkinson's disease. Neuroreport 2006;17:1215–18 doi:10.1097/01.wnr.0000227984.84927.a7 pmid:16837857
CrossRef PubMed
8.↵
2. Naidich TP,
3. Duvernoy HM
. Duvernoy's Atlas of the Human Brain Stem and Cerebellum: High-Field MRI, Surface Anatomy, Internal Structure, Vascularization and 3D Sectional Anatomy. New York: Springer-Verlag; 2009
9.↵
2. Schwarz ST,
3. Rittman T,
4. Gontu V, et al
. T1-weighted MRI shows stage-dependent substantia nigra signal loss in Parkinson's disease. Mov Disord 2011;26:1633–38 doi:10.1002/mds.23722 pmid:21491489
CrossRef PubMed
10.↵
2. Reimão S,
3. Pita Lobo P,
4. Neutel D, et al
. Substantia nigra neuromelanin magnetic resonance imaging in de novo Parkinson's disease patients. Eur J Neurol 2015;22:540–46 doi:10.1111/ene.12613 pmid:25534480
CrossRef PubMed
11.↵
2. Haber SN
. The primate basal ganglia: parallel and integrative networks. J Chem Neuroanat 2003;26:317–30 doi:10.1016/j.jchemneu.2003.10.003 pmid:14729134
CrossRef PubMed
12.↵
2. Jellinger KA
. Neuropathology of sporadic Parkinson's disease: evaluation and changes of concepts. Mov Disord 2012;27:8–30 doi:10.1002/mds.23795 pmid:22081500
CrossRef PubMed
13.↵
2. Blazejewska AI,
3. Schwarz ST,
4. Pitiot A, et al
. Visualization of nigrosome 1 and its loss in PD: pathoanatomical correlation and in vivo 7 T MRI. Neurology 2013;81:534–40 doi:10.1212/WNL.0b013e31829e6fd2 pmid:23843466
Abstract/FREE Full Text
14.↵
2. Reiter E,
3. Mueller C,
4. Pinter B, et al
. Dorsolateral nigral hyperintensity on 3.0T susceptibility-weighted imaging in neurodegenerative Parkinsonism. Mov Disord 2015;30:1068–76 doi:10.1002/mds.26171 pmid:25773707
CrossRef PubMed
15.↵
2. Reimão S,
3. Pita Lobo P,
4. Neutel D, et al
. Quantitative analysis versus visual assessment of neuromelanin MR imaging for the diagnosis of Parkinson's disease. J Parkinsons Dis 2015;5:561–67 doi:10.3233/JPD-150551 pmid:26406136
CrossRef PubMed
16.↵
2. Ohtsuka C,
3. Sasaki M,
4. Konno K, et al
. Differentiation of early-stage parkinsonisms using neuromelanin-sensitive magnetic resonance imaging. Parkinsonism Relat Disord 2014;20:755–60 doi:10.1016/j.parkreldis.2014.04.005 pmid:24768616
CrossRef PubMed
17.↵
2. Castellanos G,
3. Fernández-Seara MA,
4. Lorenzo-Betancor O, et al
. Automated neuromelanin imaging as a diagnostic biomarker for Parkinson's disease. Mov Disord 2015;30:945–52 doi:10.1002/mds.26201 pmid:25772492
CrossRef PubMed
18.↵
2. Yushkevich PA,
3. Piven J,
4. Hazlett HC, et al
. User-guided 3D active contour segmentation of anatomical structures: significantly improved efficiency and reliability. Neuroimage 2006;31:1116–28 doi:10.1016/j.neuroimage.2006.01.015 pmid:16545965
CrossRef PubMed
19.↵
2. Langley J,
3. Huddleston DE,
4. Merritt M, et al
. Diffusion tensor imaging of the substantia nigra in Parkinson's disease revisited. Hum Brain Mapp 2016;37:2547–56 doi:10.1002/hbm.23192 pmid:27029026
CrossRef PubMed
20.↵
2. Schwarz ST,
3. Afzal M,
4. Morgan PS, et al
. The ‘swallow tail’ appearance of the healthy nigrosome: a new accurate test of Parkinson's disease—a case-control and retrospective cross-sectional MRI study at 3T. PLoS One 2014;9:e93814 doi:10.1371/journal.pone.0093814 pmid:24710392
CrossRef PubMed
21.↵
2. Nichols TE,
3. Holmes AP
. Nonparametric permutation tests for functional neuroimaging: a primer with examples. Hum Brain Mapp 2002;15:1–25 doi:10.1002/hbm.1058 pmid:11747097
CrossRef PubMed
22.↵
2. Braak H,
3. Del Tredici K,
4. Rüb U, et al
. Staging of brain pathology related to sporadic Parkinson's disease. Neurobiol Aging 2003;24:197–211 doi:10.1016/S0197-4580(02)00065-9 pmid:12498954
CrossRef PubMed
23.↵
2. Kastner A,
3. Hirsch EC,
4. Lejeune O, et al
. Is the vulnerability of neurons in the substantia nigra of patients with Parkinson's disease related to their neuromelanin content? J Neurochem 1992;59:1080–89 doi:10.1111/j.1471-4159.1992.tb08350.x pmid:1494900
CrossRef PubMed
24.↵
2. Kashihara K,
3. Shinya T,
4. Higaki F
. Neuromelanin magnetic resonance imaging of nigral volume loss in patients with Parkinson's disease. J Clin Neurosci 2011;18:1093–96 doi:10.1016/j.jocn.2010.08.043 pmid:21719292
CrossRef PubMed
25.↵
2. Kempster PA,
3. Gibb WR,
4. Stern GM, et al
. Asymmetry of substantia nigra neuronal loss in Parkinson's disease and its relevance to the mechanism of levodopa related motor fluctuations. J Neurol Neurosurg Psychiatry 1989;52:72–76 doi:10.1136/jnnp.52.1.72 pmid:2709038
Abstract/FREE Full Text
26.↵
2. Menke RA,
3. Scholz J,
4. Miller KL, et al
. MRI characteristics of the substantia nigra in Parkinson's disease: a combined quantitative T1 and DTI study. Neuroimage 2009;47:435–41 doi:10.1016/j.neuroimage.2009.05.017 pmid:19447183
CrossRef PubMed
27.↵
2. Wang JJ,
3. Lin WY,
4. Lu CS, et al
. Parkinson disease: diagnostic utility of diffusion kurtosis imaging. Radiology 2011;261:210–17 doi:10.1148/radiol.11102277 pmid:21771952
CrossRef PubMed
28.↵
2. Ofori E,
3. Pasternak O,
4. Planetta PJ, et al
. Increased free water in the substantia nigra of Parkinson's disease: a single-site and multi-site study. Neurobiol Aging 2015;36:1097–104 doi:10.1016/j.neurobiolaging.2014.10.029 pmid:25467638
CrossRef PubMed
29.↵
2. Tosk JM,
3. Holshouser BA,
4. Aloia RC, et al
. Effects of the interaction between ferric iron and L-dopa melanin on T1 and T2 relaxation times determined by magnetic resonance imaging. Magn Reson Med 1992;26:40–45 doi:10.1002/mrm.1910260105 pmid:1625565
CrossRef PubMed
30.↵
2. Kwon DH,
3. Kim JM,
4. Oh SH, et al
. Seven-Tesla magnetic resonance images of the substantia nigra in Parkinson disease. Ann Neurol 2012;71:267–77 doi:10.1002/ana.22592 pmid:22367998
CrossRef PubMed
31.↵
2. Cosottini M,
3. Frosini D,
4. Pesaresi I, et al
. Comparison of 3T and 7T susceptibility-weighted angiography of the substantia nigra in diagnosing Parkinson disease. AJNR Am J Neuroradiol 2015;36:461–66 doi:10.3174/ajnr.A4158 pmid:25376811
Abstract/FREE Full Text
32.↵
2. Mahlknecht P,
3. Krismer F,
4. Poewe W, et al
. Meta-analysis of dorsolateral nigral hyperintensity on magnetic resonance imaging as a marker for Parkinson's disease. Mov Disord 2017;32:619–23 doi:10.1002/mds.26932 pmid:28151553
CrossRef PubMed
33.↵
2. Michaeli S,
3. Oz G,
4. Sorce DJ, et al
. Assessment of brain iron and neuronal integrity in patients with Parkinson's disease using novel MRI contrasts. Mov Disord 2007;22:334–40 doi:10.1002/mds.21227 pmid:17149719
CrossRef PubMed
34.↵
2. Esterhammer R,
3. Seppi K,
4. Reiter E, et al
. Potential of diffusion tensor imaging and relaxometry for the detection of specific pathological alterations in Parkinson's Disease (PD). PLoS One 2015;10:e0145493 doi:10.1371/journal.pone.0145493 pmid:26713760
CrossRef PubMed
35.↵
2. Schwarz J,
3. Weis S,
4. Kraft E, et al
. Signal changes on MRI and increases in reactive microgliosis, astrogliosis, and iron in the putamen of two patients with multiple system atrophy. J Neurol Neurosurg Psychiatry 1996;60:98–101 doi:10.1136/jnnp.60.1.98 pmid:8558163
Abstract/FREE Full Text
36.↵
2. Pujol J,
3. Junqué C,
4. Vendrell P, et al
. Reduction of the substantia nigra width and motor decline in aging and Parkinson's disease. Arch Neurol 1992;49:1119–22 doi:10.1001/archneur.1992.00530350033015 pmid:1444876
CrossRef PubMed

Received January 10, 2018.
Accepted after revision April 29, 2018.

View Abstract

In this issue

Download PDF

Email Article

Citation Tools

Purchase

Cited By...

More in this TOC Section

Show more ADULT BRAIN

[1] 1.↵

Fearnley JM,
Lees AJ
. Ageing and Parkinson's disease: substantia nigra regional selectivity. Brain 1991;114(Pt 5):2283–301 doi:10.1093/brain/114.5.2283 pmid:1933245
CrossRef PubMed

[3] Fearnley JM,

[4] Lees AJ

[5] 2.↵

Du G,
Lewis MM,
Styner M, et al
. Combined R2* and diffusion tensor imaging changes in the substantia nigra in Parkinson's disease. Mov Disord 2011;26:1627–32 doi:10.1002/mds.23643 pmid:21618607
CrossRef PubMed

[7] Du G,

[8] Lewis MM,

[9] Styner M, et al

[10] 3.↵

Péran P,
Cherubini A,
Assogna F, et al
. Magnetic resonance imaging markers of Parkinson's disease nigrostriatal signature. Brain 2010;133:3423–33 doi:10.1093/brain/awq212 pmid:20736190
CrossRef PubMed

[12] Péran P,

[13] Cherubini A,

[14] Assogna F, et al

[15] 4.↵

Vaillancourt DE,
Spraker MB,
Prodoehl J, et al
. High-resolution diffusion tensor imaging in the substantia nigra of de novo Parkinson disease. Neurology 2009;72:1378–84 doi:10.1212/01.wnl.0000340982.01727.6e pmid:19129507
Abstract/FREE Full Text

[17] Vaillancourt DE,

[18] Spraker MB,

[19] Prodoehl J, et al

[20] 5.↵

Schwarz ST,
Abaei M,
Gontu V, et al
. Diffusion tensor imaging of nigral degeneration in Parkinson's disease: a region-of-interest and voxel-based study at 3 T and systematic review with meta-analysis. Neuroimage Clin 2013;3:481–88 doi:10.1016/j.nicl.2013.10.006 pmid:24273730
CrossRef PubMed

[22] Schwarz ST,

[23] Abaei M,

[24] Gontu V, et al

[25] 6.↵

Barbosa JH,
Santos AC,
Tumas V, et al
. Quantifying brain iron deposition in patients with Parkinson's disease using quantitative susceptibility mapping, R2 and R2. Magn Reson Imaging 2015;33:559–65 doi:10.1016/j.mri.2015.02.021 pmid:25721997
CrossRef PubMed

[27] Barbosa JH,

[28] Santos AC,

[29] Tumas V, et al

[30] 7.↵

Sasaki M,
Shibata E,
Tohyama K, et al
. Neuromelanin magnetic resonance imaging of locus ceruleus and substantia nigra in Parkinson's disease. Neuroreport 2006;17:1215–18 doi:10.1097/01.wnr.0000227984.84927.a7 pmid:16837857
CrossRef PubMed

[32] Sasaki M,

[33] Shibata E,

[34] Tohyama K, et al

[35] 8.↵

Naidich TP,
Duvernoy HM
. Duvernoy's Atlas of the Human Brain Stem and Cerebellum: High-Field MRI, Surface Anatomy, Internal Structure, Vascularization and 3D Sectional Anatomy. New York: Springer-Verlag; 2009

[37] Naidich TP,

[38] Duvernoy HM

[39] 9.↵

Schwarz ST,
Rittman T,
Gontu V, et al
. T1-weighted MRI shows stage-dependent substantia nigra signal loss in Parkinson's disease. Mov Disord 2011;26:1633–38 doi:10.1002/mds.23722 pmid:21491489
CrossRef PubMed

[41] Schwarz ST,

[42] Rittman T,

[43] Gontu V, et al

[44] 10.↵

Reimão S,
Pita Lobo P,
Neutel D, et al
. Substantia nigra neuromelanin magnetic resonance imaging in de novo Parkinson's disease patients. Eur J Neurol 2015;22:540–46 doi:10.1111/ene.12613 pmid:25534480
CrossRef PubMed

[46] Reimão S,

[47] Pita Lobo P,

[48] Neutel D, et al

[49] 11.↵

Haber SN
. The primate basal ganglia: parallel and integrative networks. J Chem Neuroanat 2003;26:317–30 doi:10.1016/j.jchemneu.2003.10.003 pmid:14729134
CrossRef PubMed

[51] Haber SN

[52] 12.↵

Jellinger KA
. Neuropathology of sporadic Parkinson's disease: evaluation and changes of concepts. Mov Disord 2012;27:8–30 doi:10.1002/mds.23795 pmid:22081500
CrossRef PubMed

[54] Jellinger KA

[55] 13.↵

Blazejewska AI,
Schwarz ST,
Pitiot A, et al
. Visualization of nigrosome 1 and its loss in PD: pathoanatomical correlation and in vivo 7 T MRI. Neurology 2013;81:534–40 doi:10.1212/WNL.0b013e31829e6fd2 pmid:23843466
Abstract/FREE Full Text

[57] Blazejewska AI,

[58] Schwarz ST,

[59] Pitiot A, et al

[60] 14.↵

Reiter E,
Mueller C,
Pinter B, et al
. Dorsolateral nigral hyperintensity on 3.0T susceptibility-weighted imaging in neurodegenerative Parkinsonism. Mov Disord 2015;30:1068–76 doi:10.1002/mds.26171 pmid:25773707
CrossRef PubMed

[62] Reiter E,

[63] Mueller C,

[64] Pinter B, et al

[65] 15.↵

Reimão S,
Pita Lobo P,
Neutel D, et al
. Quantitative analysis versus visual assessment of neuromelanin MR imaging for the diagnosis of Parkinson's disease. J Parkinsons Dis 2015;5:561–67 doi:10.3233/JPD-150551 pmid:26406136
CrossRef PubMed

[67] Reimão S,

[68] Pita Lobo P,

[69] Neutel D, et al

[70] 16.↵

Ohtsuka C,
Sasaki M,
Konno K, et al
. Differentiation of early-stage parkinsonisms using neuromelanin-sensitive magnetic resonance imaging. Parkinsonism Relat Disord 2014;20:755–60 doi:10.1016/j.parkreldis.2014.04.005 pmid:24768616
CrossRef PubMed

[72] Ohtsuka C,

[73] Sasaki M,

[74] Konno K, et al

[75] 17.↵

Castellanos G,
Fernández-Seara MA,
Lorenzo-Betancor O, et al
. Automated neuromelanin imaging as a diagnostic biomarker for Parkinson's disease. Mov Disord 2015;30:945–52 doi:10.1002/mds.26201 pmid:25772492
CrossRef PubMed

[77] Castellanos G,

[78] Fernández-Seara MA,

[79] Lorenzo-Betancor O, et al

[80] 18.↵

Yushkevich PA,
Piven J,
Hazlett HC, et al
. User-guided 3D active contour segmentation of anatomical structures: significantly improved efficiency and reliability. Neuroimage 2006;31:1116–28 doi:10.1016/j.neuroimage.2006.01.015 pmid:16545965
CrossRef PubMed

[82] Yushkevich PA,

[83] Piven J,

[84] Hazlett HC, et al

[85] 19.↵

Langley J,
Huddleston DE,
Merritt M, et al
. Diffusion tensor imaging of the substantia nigra in Parkinson's disease revisited. Hum Brain Mapp 2016;37:2547–56 doi:10.1002/hbm.23192 pmid:27029026
CrossRef PubMed

[87] Langley J,

[88] Huddleston DE,

[89] Merritt M, et al

[90] 20.↵

Schwarz ST,
Afzal M,
Morgan PS, et al
. The ‘swallow tail’ appearance of the healthy nigrosome: a new accurate test of Parkinson's disease—a case-control and retrospective cross-sectional MRI study at 3T. PLoS One 2014;9:e93814 doi:10.1371/journal.pone.0093814 pmid:24710392
CrossRef PubMed

[92] Schwarz ST,

[93] Afzal M,

[94] Morgan PS, et al

[95] 21.↵

Nichols TE,
Holmes AP
. Nonparametric permutation tests for functional neuroimaging: a primer with examples. Hum Brain Mapp 2002;15:1–25 doi:10.1002/hbm.1058 pmid:11747097
CrossRef PubMed

[97] Nichols TE,

[98] Holmes AP

[99] 22.↵

Braak H,
Del Tredici K,
Rüb U, et al
. Staging of brain pathology related to sporadic Parkinson's disease. Neurobiol Aging 2003;24:197–211 doi:10.1016/S0197-4580(02)00065-9 pmid:12498954
CrossRef PubMed

[101] Braak H,

[102] Del Tredici K,

[103] Rüb U, et al

[104] 23.↵

Kastner A,
Hirsch EC,
Lejeune O, et al
. Is the vulnerability of neurons in the substantia nigra of patients with Parkinson's disease related to their neuromelanin content? J Neurochem 1992;59:1080–89 doi:10.1111/j.1471-4159.1992.tb08350.x pmid:1494900
CrossRef PubMed

[106] Kastner A,

[107] Hirsch EC,

[108] Lejeune O, et al

[109] 24.↵

Kashihara K,
Shinya T,
Higaki F
. Neuromelanin magnetic resonance imaging of nigral volume loss in patients with Parkinson's disease. J Clin Neurosci 2011;18:1093–96 doi:10.1016/j.jocn.2010.08.043 pmid:21719292
CrossRef PubMed

[111] Kashihara K,

[112] Shinya T,

[113] Higaki F

[114] 25.↵

Kempster PA,
Gibb WR,
Stern GM, et al
. Asymmetry of substantia nigra neuronal loss in Parkinson's disease and its relevance to the mechanism of levodopa related motor fluctuations. J Neurol Neurosurg Psychiatry 1989;52:72–76 doi:10.1136/jnnp.52.1.72 pmid:2709038
Abstract/FREE Full Text

[116] Kempster PA,

[117] Gibb WR,

[118] Stern GM, et al

[119] 26.↵

Menke RA,
Scholz J,
Miller KL, et al
. MRI characteristics of the substantia nigra in Parkinson's disease: a combined quantitative T1 and DTI study. Neuroimage 2009;47:435–41 doi:10.1016/j.neuroimage.2009.05.017 pmid:19447183
CrossRef PubMed

[121] Menke RA,

[122] Scholz J,

[123] Miller KL, et al

[124] 27.↵

Wang JJ,
Lin WY,
Lu CS, et al
. Parkinson disease: diagnostic utility of diffusion kurtosis imaging. Radiology 2011;261:210–17 doi:10.1148/radiol.11102277 pmid:21771952
CrossRef PubMed

[126] Wang JJ,

[127] Lin WY,

[128] Lu CS, et al

[129] 28.↵

Ofori E,
Pasternak O,
Planetta PJ, et al
. Increased free water in the substantia nigra of Parkinson's disease: a single-site and multi-site study. Neurobiol Aging 2015;36:1097–104 doi:10.1016/j.neurobiolaging.2014.10.029 pmid:25467638
CrossRef PubMed

[131] Ofori E,

[132] Pasternak O,

[133] Planetta PJ, et al

[134] 29.↵

Tosk JM,
Holshouser BA,
Aloia RC, et al
. Effects of the interaction between ferric iron and L-dopa melanin on T1 and T2 relaxation times determined by magnetic resonance imaging. Magn Reson Med 1992;26:40–45 doi:10.1002/mrm.1910260105 pmid:1625565
CrossRef PubMed

[136] Tosk JM,

[137] Holshouser BA,

[138] Aloia RC, et al

[139] 30.↵

Kwon DH,
Kim JM,
Oh SH, et al
. Seven-Tesla magnetic resonance images of the substantia nigra in Parkinson disease. Ann Neurol 2012;71:267–77 doi:10.1002/ana.22592 pmid:22367998
CrossRef PubMed

[141] Kwon DH,

[142] Kim JM,

[143] Oh SH, et al

[144] 31.↵

Cosottini M,
Frosini D,
Pesaresi I, et al
. Comparison of 3T and 7T susceptibility-weighted angiography of the substantia nigra in diagnosing Parkinson disease. AJNR Am J Neuroradiol 2015;36:461–66 doi:10.3174/ajnr.A4158 pmid:25376811
Abstract/FREE Full Text

[146] Cosottini M,

[147] Frosini D,

[148] Pesaresi I, et al

[149] 32.↵

Mahlknecht P,
Krismer F,
Poewe W, et al
. Meta-analysis of dorsolateral nigral hyperintensity on magnetic resonance imaging as a marker for Parkinson's disease. Mov Disord 2017;32:619–23 doi:10.1002/mds.26932 pmid:28151553
CrossRef PubMed

[151] Mahlknecht P,

[152] Krismer F,

[153] Poewe W, et al

[154] 33.↵

Michaeli S,
Oz G,
Sorce DJ, et al
. Assessment of brain iron and neuronal integrity in patients with Parkinson's disease using novel MRI contrasts. Mov Disord 2007;22:334–40 doi:10.1002/mds.21227 pmid:17149719
CrossRef PubMed

[156] Michaeli S,

[157] Oz G,

[158] Sorce DJ, et al

[159] 34.↵

Esterhammer R,
Seppi K,
Reiter E, et al
. Potential of diffusion tensor imaging and relaxometry for the detection of specific pathological alterations in Parkinson's Disease (PD). PLoS One 2015;10:e0145493 doi:10.1371/journal.pone.0145493 pmid:26713760
CrossRef PubMed

[161] Esterhammer R,

[162] Seppi K,

[163] Reiter E, et al

[164] 35.↵

Schwarz J,
Weis S,
Kraft E, et al
. Signal changes on MRI and increases in reactive microgliosis, astrogliosis, and iron in the putamen of two patients with multiple system atrophy. J Neurol Neurosurg Psychiatry 1996;60:98–101 doi:10.1136/jnnp.60.1.98 pmid:8558163
Abstract/FREE Full Text

[166] Schwarz J,

[167] Weis S,

[168] Kraft E, et al

[169] 36.↵

Pujol J,
Junqué C,
Vendrell P, et al
. Reduction of the substantia nigra width and motor decline in aging and Parkinson's disease. Arch Neurol 1992;49:1119–22 doi:10.1001/archneur.1992.00530350033015 pmid:1444876
CrossRef PubMed

[171] Pujol J,

[172] Junqué C,

[173] Vendrell P, et al

Main menu

User menu

Search

Comparative Study of MRI Biomarkers in the Substantia Nigra to Discriminate Idiopathic Parkinson Disease

Abstract

ABBREVIATIONS:

Materials and Methods

Subjects

Clinical and Neurologic Examination

MR Imaging Acquisition

Image Analysis

ROIs.

Quantitative Analysis.

Blind Visual Analysis.

Statistical Analysis

Results

Population Characterization

Quantitative MR Imaging Data Analysis

NM-Sensitive Volume.

NM-Sensitive Signal.

DTI Parameters.

R2*.

7T T2*WI SN Volume.

Best Variable Combinations.

Qualitative Visual Analysis

NM-Sensitive Images.

7T T2-weighted Images.

Correlation between MR Imaging Data and Clinical Changes

Discussion

Conclusions

Footnotes

References

In this issue

Citation Manager Formats

Jump to section

Related Articles

Cited By...

More in this TOC Section

Similar Articles

News and Updates

Resources

Opportunities

American Society of Neuroradiology
