Arterial Spin-Labeling MR Imaging in the Detection of Intracranial Arteriovenous Malformations in Patients with Hereditary Hemorrhagic Telangiectasia

Adam Alyafaie; Woody Han; Yi Li; Samuel A. Vydro; Maya Vella; Torianna L. Truong; Lindsay Park; Daniel Langston; Helen Kim; Miles B. Conrad; Steven W. Hetts

doi:10.3174/ajnr.A8281

Abstract

BACKGROUND AND PURPOSE: Hereditary hemorrhagic telangiectasia (HHT) is an autosomal dominant disease that causes vascular malformations in a variety of organs and tissues, including brain AVMs. Because brain AVMs have the potential to cause disabling or fatal intracranial hemorrhage, detection of these lesions before rupture is the goal of screening MR imaging/MRA examinations in patients with HHT. Prior studies have demonstrated superior sensitivity for HHT-related brain AVMs by using postcontrast MR imaging sequences as compared with MRA alone. We now present data regarding the incremental benefit of including arterial spin-labeling (ASL) perfusion sequences as part of MR imaging/MRA screening in patients with this condition.

MATERIALS AND METHODS: We retrospectively analyzed 831 patients at the UCSF Hereditary Hemorrhagic Telangiectasia Center of Excellence. Of these, 42 patients had complete MR imaging/MRA, ASL perfusion scans, and criterion-standard DSA data. Two neuroradiologists reviewed imaging studies and a third provided adjudication when needed.

RESULTS: Eight patients had no brain AVMs detected on DSA. The remaining 34 patients had 57 brain AVMs on DSA. Of the 57 identified AVMs, 51 (89.5%) were detected on ASL and 43 (75.4%) were detected on conventional MR imaging/MRA sequences (P = .049), with 8 lesions detected on ASL perfusion but not on conventional MR imaging.

CONCLUSIONS: ASL provides increased sensitivity for brain AVMs in patients with HHT. Inclusion of ASL should be considered as part of comprehensive MR imaging/MRA screening protocols for institutions taking care of patients with HHT.

ABBREVIATIONS:

ACVRL1: activin A receptor type II-like 1 gene
ASL: arterial spin-labeling
ENG: endoglin gene
HHT: hereditary hemorrhagic telangiectasia
PCASL: pseudocontinuous arterial spin-labeling

Hereditary hemorrhagic telangiectasia (HHT), also known as Osler-Weber-Rendu disease, is an autosomal-dominant disease with a prevalence of 1/5000 and results in the formation of dysplastic vessels.¹ These vascular malformations can form on mucocutaneous surfaces or within internal organs.² Diagnosis of HHT is established through either the clinical Curacao criteria or genetic testing.³ The Curacao criteria, developed in 2000 at the HHT Scientific Advisory Board Meeting to standardize clinical diagnoses of HHT, include: recurrent epistaxis, multiple cutaneous or mucocutaneous telangiectasias in characteristic locations, visceral AVMs, and a family history of HHT. HHT is suspected when at least 2 criteria are met, though diagnosis requires 3.⁴ Diagnosis can also be made if an individual tests positive for a known causative mutation including those in the endoglin (ENG), activin A receptor type II-like 1 (ACVRL1), GDF2, and SMAD4 genes.³

While epistaxis is the most frequently presenting symptom of HHT, complications secondary to pulmonary and cerebral vascular malformations can result in severe morbidity and mortality.⁵ Studies have shown that approximately 23% of individuals with HHT develop cerebral vascular malformations, some of which, including capillary telangiectasias, can be very small and missed on MR imaging.^3,6 AVMs are the most common cerebral lesions and have a risk of rupture of 0.4%–1.3% per year per patient.^7⇓⇓-10 The current criterion standard for diagnosing AVMs is via catheter DSA, an invasive test.¹¹ Current guidelines recommend screening all adult patients with suspected or definite HHT for cerebral vascular malformations by using MR imaging with and without contrast administration with at least 1 sequence sensitive to the presence of blood products.^3,12,13 For children, recommendations are for brain AVM screening as soon as possible after birth by using MR imaging.^3,13 Our prior study showed that the sensitivity and specificity of MR imaging as a whole in detecting brain AVMs in patients with HHT were 80.0% and 94.4%, respectively, with 3D-T1 and 2D-T1 postgadolinium sequences being the most sensitive, by using DSA as the criterion standard.¹⁴ Other sequences evaluated in the study were T2, SWI, and MRA.

Arterial spin-labeling (ASL) MR perfusion imaging was conceived nearly 30 years ago and relies on magnetically labeled arterial blood water protons as an endogenous tracer to measure tissue perfusion.^15⇓-17 This noninvasive noncontrast MR imaging technique is particularly useful because it does not require radioactive tracers or exogenous contrast agents, allowing it to be performed on a broad range of patient populations that may otherwise not tolerate contrast-enhanced studies.¹⁸ Further expanding the clinical utility of ASL, slight alterations can be made to the standard pseudocontinuous arterial spin-labeling (PCASL) sequence protocol to optimize its sensitivity for different pathologies, such as acute ischemic strokes, tumors, AVMs, and others.¹⁹ One study found ASL to have a sensitivity of 95% for detecting intracranial arteriovenous shunting.²⁰ This sensitivity arises from the high concentration of labeled protons flowing through shunts as the protons bypass the microvascular/tissue network and are directly delivered to the draining veins in AVMs. However, there are limited data demonstrating the utility of ASL as a screening tool in the detection of intracranial AVMs in patients with HHT. Because detection of AVMs is essential in the prevention of intracranial hemorrhage in persons with HHT, improvements in screening with noninvasive imaging techniques may benefit to patients with HHT. This study aims to evaluate the added value of ASL perfusion in the HHT population by comparing the sensitivity of MR imaging with ASL to that of conventional MR imaging without ASL.

MATERIALS AND METHODS

Subject Inclusion Criteria

All patients referred to the University of California, San Francisco HHT Center of Excellence by November 2022 underwent screening for potential inclusion in this retrospective study (n = 831). Approval for this study was obtained from the University of California, San Francisco Institutional Review Board. Patients were further narrowed down to include those who subsequently underwent brain imaging or had history that raised suspicion of possible brain AVMs (n = 154). Patient charts were reviewed, and pertinent data recorded included sex, age, Curacao criteria, genetic testing, and dates of cerebral imaging (including MR imaging and DSA). Mean ± standard deviation and median age for the cohort were calculated. Inclusion criteria for the study included suspected or definite diagnosis of HHT via Curacao criteria or genetic testing and at least 1 brain MR imaging with ASL perfusion and 1 cerebral DSA within the same stage of the patient’s initial evaluation or ongoing treatment/management. Any patient whose MR imaging/ASL examinations were obtained in a separate treatment/management stage as the DSA examination were excluded to minimize the influence of treatments (such as interval gamma knife or surgical resection) on the sensitivity or specificity of MR imaging/ASL. This is a similar cohort as our prior study,¹⁴ updated with patients enrolled since that time.

Image Analysis

A fellowship-trained neurointerventional radiologist (S.W.H.) reviewed the cerebral DSA images for all 42 patients and recorded the total number and specific locations of intracranial AVMs, which served as the reference standard for this study. The first MR with ASL imaging that occurred immediately before the DSA was retrospectively reviewed by 2 fellowship-trained neuroradiologists (W.H. and Y.L.). For patients with multiple ASL imaging, the one that was closest in time to the patient’s first DSA was selected. A third fellowship-trained neuroradiologist (S.W.H.) adjudicated any discrepancies between the 2 readings. The neuroradiologists first reviewed the MR imaging as a whole and recorded the total number of cerebral AVMs detected on conventional sequences only, as well as which individual sequences the AVMs were visible on (SWI, T2-weighted, MRA, 2D-T1-weighted postgadolinium, and 3D-T1-weighted postgadolinium). The readers then reviewed the ASL perfusion images available for each of these MR imaging examinations in the context of the MR imaging as a whole and recorded their results for detection of cerebral AVM in a binary fashion.

A number of these MR images were performed at different institutions and on different scanners with varying field strengths and other parameters. As a result, there was no standardized set of sequences and parameters for the MR images and ASL perfusion studies. All ASL sequences were performed with PCASL. The standard postlabeling delay time for adults and pediatric patients were 2025 ms and 1500 ms, respectively. No additional postprocessing or adjustment was performed on ASL images acquired at outside institutions. Using DSA as the reference standard, true- and false-positives for ASL perfusion and conventional MR imaging were calculated for each lesion. From there, sensitivity for ASL and conventional MR imaging were calculated and compared. Cohen κ for interreader reliability between the 2 readers for both ASL perfusion and conventional MR imaging sequences was also calculated. Statistical analyses were performed by using Excel (Microsoft). The McNemar test was used to compare MR imaging and ASL for only the DSA-positive AVMs to determine whether there was a statistically significant difference (P < .05) between conventional MR imaging alone and MR imaging plus ASL.

RESULTS

Of the 343 patients reviewed, 38 patients met all inclusion criteria. An additional 4 patients had a Curacao score of 1 and either had no genetic testing available or tested negative for known HHT-causing mutations. However, clinical suspicion for HHT remained high for these 4 patients because some manifestations of HHT, such as epistaxis and oral/dermal telangiectasias, may not occur until later in life, rendering Curacao criteria less accurate in young patients.^21⇓-23 Therefore, these 4 patients were included in the study, resulting in 42 patients total.

The study consisted of 42 patients ranging in age from 1.5 months to 71 years. The mean age at the time of MR imaging with ASL was 17 ± 18 years and 60% of the patients were female (Table 1). The median time between ASL and DSA was 151 days with an interquartile range of 617. Most patients had a Curacao score of 2 (43%). Thirty-six patients (85%) underwent genetic testing and 50% of them tested positive for mutations in the ENG gene. Five patients had no genetic testing data available. Three of these 5 patients had a Curacao score of 2, while the other 2 patients had a Curacao score of 1. These 2 patients were still included because their ages were only 1.5 and 2.5 months at the time of ASL imaging and they were determined to have a high likelihood of HHT despite their Curacao score.

View this table:

Table 1:

Demographics of patients included in the study

A total of 8 patients had no brain AVMs detected on DSA. The remaining 34 patients had a total of 57 intracranial AVMs that were positive on DSA. These 57 AVMs were located in a variety of locations, with the frontal lobe being the most common (Online Supplemental Data). Of the 57 identified lesions, 51 (89.5%) were positive on ASL and 43 (75.4%) were positive on conventional MR imaging (P = .0455, McNemar), with 8 lesions detected on ASL perfusion but not on conventional MR imaging. An example of these lesions can be seen in Fig 1, which demonstrates small subcentimeter nidus “microAVMs,” which are otherwise occult on conventional MR imaging sequences and are a common cerebrovascular manifestation of patients with HHT (see Online Supplemental Data for more examples). There were 3 lesions identified on ASL and 1 lesion on MR imaging that were negative on DSA. One such example is seen in Fig 2, in which postoperative changes such as pericavitary hyperemia and truncation of the arterial feeders were likely reflected on ASL perfusion imaging as arterial transit artifact. Table 2 summarizes the total lesions detected on ASL and conventional MR imaging, with Cohen κ interreader reliability coefficient displayed for both ASL perfusion as well as conventional MR imaging. Of all the conventional sequences, 3D-T1 postgadolinium had the highest sensitivity, with 41/56 (73%). Not every patient had each MR imaging sequence available, thus the total number of lesions for each sequence differed. The Online Supplemental Data present the sensitivity, specificity, positive predictive value, and negative predictive value of ASL perfusion, conventional MR imaging, and each individual sequence.

FIG 1.

Adult patient with genetically confirmed HHT and mild epistaxis, presenting for a screening brain MR imaging and MRA. A, Postprocessed ASL image with a focus of increased signal along the right superior frontal gyrus. B and C, Postgadolinium 3D BRAVO (3D brain volume) and noncontrast time-of-flight MRA, respectively, with no corresponding vascular abnormality demonstrated on these conventional MR imaging sequences. Frontal (D) and lateral (E) DSA images acquired from a selective right ICA injection in the late arterial phase demonstrating an ill-defined compact 12-mm AVM nidus (blue arrows) associated with early filling of a superficial cortical vein (yellow arrows) along the right superior frontal gyrus draining into the superior sagittal sinus.

FIG 2.

Teenage patient presenting with acute onset right hemiparesis and aphasia, found to have a large left frontoparietal hematoma with an associated vascular malformation suspicious for a ruptured AVM on noninvasive imaging. The patient was emergently taken to the operating room for decompressive hemicraniectomy and AVM resection. No preoperative angiogram was performed. Patient currently meets 1 of 4 Curacao criteria for HHT with genetic testing pending. However, given young age at presentation, clinical suspicion remained high for underlying HHT, because certain clinical manifestations such as epistaxis and oral/dermal telangiectasias, may not occur until later in life. A, ASL acquired on postoperative day 1 demonstrating a focus of increased signal along the left posterosuperior insula (blue arrow). Noncontrast time-of-flight MRA (B) and SWI (C) with expected postoperative changes in the operative bed, with no abnormality on MRA to suggest residual shunting. Frontal (D) and lateral (E) DSA images demonstrating abrupt cutoff/truncation of a posterior insular left M3 MCA branch (likely feeding artery) associated with a surgical clip, compatible with expected postoperative change. This finding corresponds to the focus of increased ASL signal and likely reflects arterial transit artifact as a result of postsurgical change rather than residual arteriovenous shunting. No residual AVM nidus or shunting was demonstrated. F, Preoperative CT angiogram demonstrating the left frontal AVM nidus in relation to the large acute left frontoparietal hematoma.

View this table:

Table 2:

Number and percentage of AVMs detected on ASL and conventional MR imaging, with κ coefficient for interreader reliability

DISCUSSION

Whereas previous studies have investigated the utility of conventional MR imaging/MRA sequences as a screening tool for intracranial AVMs in patients with HHT,¹⁴ additional evidence has emerged over the past few years suggesting that ASL may be more sensitive than conventional MR imaging/MRA in the detection of AVMs and other intracranial arteriovenous shunting lesions.^19,24,25 Our study demonstrates that ASL perfusion, when interpreted in conjunction with conventional MR imaging/MRA, provides additional value in the detection of brain AVMs in patients with HHT compared with conventional MR imaging/MRA sequences alone, by using DSA as the criterion standard. Of the 57 DSA-confirmed AVMs in this patient population, the sensitivity of ASL perfusion (89.5%) in detecting these lesions was significantly higher than that of other conventional MR imaging/MRA sequences (28.1%–75.4%), with 8 of 57 DSA-confirmed AVMs detected on ASL but not on conventional MR imaging/MRA sequences. These values are also concordant with previously reported values in the literature regarding each technique.^19,24,25 Overall, our study provides support for the use of ASL in addition to conventional MR imaging as a screening tool for brain AVMs in the HHT population, with strong interreader reliability and statistically significant increase in sensitivity for this cohort of patients.

Although this incremental value of ASL over conventional MR imaging/MRA in the detection of brain AVMs is well supported by our study, we must caution that these findings are only valid under the premise of ASL being a component sequence as part of a comprehensive MR imaging/MRA evaluation for patients with HHT. As previously mentioned, the blinded readers and adjudicator individually reviewed the ASL images of each study in the context of the MR imaging as a whole, which more accurately reflects how these studies are interpreted in clinical practice. As such, our data also support the essential role that conventional MR imaging continues to play in the detection of brain AVMs in the HHT population, with a sensitivity of 74.5%, similar to a previous study.¹⁴

The limitations of our study must also be noted, foremost of which is the heterogeneity of the MR imaging that was reviewed. Because the studies for this cohort of patients were performed at multiple different institutions, unavoidable variations existed in selection of protocol, magnetic field strength, the types of sequences obtained, the field of view for each sequence, and whether gadolinium-based contrast was given. For instance, the limited time-of-flight MRA field of view on many studies as well as the lack of postcontrast sequences in a few studies may account for some of the relatively decreased sensitivity of conventional MR imaging. Although all studies used the PCASL technique, readout methods varied between scanners and institutions. In ASL, images are acquired downstream from the initial blood labeling following a specified postlabeling delay, yielding a field of view that generally includes the entirety of the brain.²⁶ Such whole-brain coverage is particularly important for this patient population, because AVMs can be present at any location in the brain, not just near the circle of Willis.

Another limitation of our study is the nonrandomized, retrospective nature of our study, in which a significantly higher proportion of patients in this cohort had one or multiple AVMs (34/42, or 81%) than what has traditionally been reported in the literature (up to 23%). This may be due to the nature of our HHT practice to perform DSA only on patients with suspicious clinical or screening MR imaging/MRA findings. It is unlikely that a de novo brain AVM formed between the time of MR imaging and DSA; there are only a few case reports of this phenomenon in the HHT population, predominantly in children.²⁷ Furthermore, this relatively low number of “control” patients with HHT but negative DSA findings in our cohort limits our evaluation of the true specificities and negative predictive values of both ASL and conventional MR imaging, potentially accounting for the wider range of specificities and lower negative predictive values when compared with our prior study.¹⁴

Finally, because ASL remains a relatively novel sequence compared with conventional MR imaging/MRA sequences, standardization of technical parameters related to the acquisition and postprocessing of ASL may not be as widespread across different institutions and imaging centers as with conventional sequences. Our institution’s HHT brain AVM screening protocol is included for readers’ reference (Online Supplemental Data). Although the 2015 consensus paper provided general guidelines for clinical applications of ASL MR imaging,²⁸ there remained a relative lack of guidance on disease-specific parameters until the updated guidelines published by the ISMRM Perfusion Study Group more recently.¹⁹ As elucidated in the literature, variability in technical parameters of ASL imaging such as the location of the labeling plane, presence of susceptibility artifact in the labeling plane or imaging plane, the postlabel delay time, and whether postprocessing software was used, all may affect quality and interpretation of the ASL images.¹⁹ The fact that interreader agreement remained relatively high in our study further highlights the potential utility of ASL with more standardized protocols across institutions as well as possible quantitative data from ASL acquisition to reduce “operator” dependence. Future studies evaluating a prospective cohort of patients with HHT scanned with the same standardized MR imaging protocols and newer ASL imaging techniques such as multidelay ASL may help to confirm the true sensitivity of each of these sequences in this population.

CONCLUSIONS

This study supports the use of ASL perfusion in conjunction with conventional MR imaging/MRA sequences as a more sensitive screening tool for cerebral AVMs in patients with HHT, when compared with conventional MR imaging sequences alone. The continued refinement of advanced MR imaging techniques such as ASL may see their sensitivity at detecting AVMs begin to approach that of the reference standard DSA, allowing for more accurate and widespread noninvasive diagnosis and risk stratification for patients with HHT.

Acknowledgments

The authors acknowledge Cure HHT for its ongoing support of the HHT patient and provider community.

Footnotes

This research was supported in part by grants to S.W.H., including NIH R01EB012031, DoD W81XWH-22-1-0178, and HRSA-22-145.
Disclosure forms provided by the authors are available with the full text and PDF of this article at www.ajnr.org.

References

1.↵
1. Kjeldsen AD,
2. Vase P,
3. Green A
. Hereditary haemorrhagic telangiectasia: a population‐based study of prevalence and mortality in Danish patients. J Intern Med 1999;245:31–9 doi:10.1046/j.1365-2796.1999.00398.x
CrossRef PubMed
2.↵
1. McDonald J,
2. Bayrak-Toydemir P,
3. Pyeritz RE
. Hereditary hemorrhagic telangiectasia: an overview of diagnosis, management, and pathogenesis. Genet Med 2011;13:607–16 doi:10.1097/GIM.0b013e3182136d32 pmid:21546842
CrossRef PubMed
3.↵
1. Faughnan ME,
2. Palda VA,
3. Garcia-Tsao G, et al
; HHT Foundation International-Guidelines Working Group. International guidelines for the diagnosis and management of hereditary haemorrhagic telangiectasia. J Med Genet 2011;48:73–87 doi:10.1136/jmg.2009.069013 pmid:19553198
Abstract/FREE Full Text
4.↵
1. Shovlin CL,
2. Guttmacher AE,
3. Buscarini E, et al
. Diagnostic criteria for hereditary hemorrhagic telangiectasia (Rendu-Osler-Weber syndrome). Am J Med Genet 2000;91:66–7 doi:10.1002/(SICI)1096-8628(20000306)91:1<66::AID-AJMG12>3.0.CO;2-P pmid:10751092
CrossRef PubMed
5.↵
1. Sautter NB,
2. Smith TL
. Hereditary hemorrhagic telangiectasia-related epistaxis: innovations in understanding and management. Int Forum Allergy Rhinol 2012;2:422–31 doi:10.1002/alr.21046 pmid:22566463
CrossRef PubMed
6.↵
1. Martín-Noguerol T,
2. Concepción-Aramendia L,
3. Lim CT, et al
. Conventional and advanced MRI evaluation of brain vascular malformations. J Neuroimaging 2021;31:428–45 doi:10.1111/jon.12853 pmid:33856735
CrossRef PubMed
7.↵
1. Maher CO,
2. Piepgras DG,
3. Brown RD, et al
. Cerebrovascular manifestations in 321 cases of hereditary hemorrhagic telangiectasia. Stroke 2001;32:877–82 doi:10.1161/01.str.32.4.877 pmid:11283386
Abstract/FREE Full Text
8.↵
1. Fulbright RK,
2. Chaloupka JC,
3. Putman CM, et al
. MR of hereditary hemorrhagic telangiectasia: prevalence and spectrum of cerebrovascular malformations. AJNR Am J Neuroradiol 1998;19:477–84 pmid:9541302
PubMed
9.↵
1. Yang W,
2. Liu A,
3. Hung AL, et al
. Lower risk of intracranial arteriovenous malformation hemorrhage in patients with hereditary hemorrhagic telangiectasia. Neurosurgery 2016;78:684–93 doi:10.1227/NEU.0000000000001103 pmid:26540357
CrossRef PubMed
10.↵
1. Willemse RB,
2. Mager JJ,
3. Westermann CJ, et al
. Bleeding risk of cerebrovascular malformations in hereditary hemorrhagic telangiectasia. J Neurosurg 2000;92:779–84 doi:10.3171/jns.2000.92.5.0779 pmid:10794291
CrossRef PubMed
11.↵
1. Willinsky RA,
2. Taylor SM,
3. TerBrugge K, et al
. Neurologic complications of cerebral angiography: prospective analysis of 2,899 procedures and review of the literature. Radiology 2003;227:522–28 doi:10.1148/radiol.2272012071 pmid:12637677
CrossRef PubMed
12.↵
1. Hetts SW,
2. Shieh JT,
3. Ohliger MA, et al
. Hereditary hemorrhagic telangiectasia: the convergence of genotype, phenotype, and imaging in modern diagnosis and management of a multisystem disease. Radiology 2021;300:17–30 doi:10.1148/radiol.2021203487 pmid:33973836
CrossRef PubMed
13.↵
1. Faughnan ME,
2. Mager JJ,
3. Hetts SW, et al
. Second International Guidelines for the Diagnosis and Management of Hereditary Hemorrhagic Telangiectasia. Ann Intern Med 2020;173:989–1001 doi:10.7326/M20-1443 pmid:32894695
CrossRef PubMed
14.↵
1. Vella M,
2. Alexander MD,
3. Mabray MC, et al
. Comparison of MRI, MRA, and DSA for detection of cerebral arteriovenous malformations in hereditary hemorrhagic telangiectasia. AJNR Am J Neuroradiol 2020;41:969–75 doi:10.3174/ajnr.A6549 pmid:32381546
Abstract/FREE Full Text
15.↵
1. Petcharunpaisan S,
2. Ramalho J,
3. Castillo M
. Arterial spin labeling in neuroimaging. World J Radiology 2010;2:384–98 doi:10.4329/wjr.v2.i10.384 pmid:21161024
CrossRef PubMed
16.↵
1. Deibler AR,
2. Pollock JM,
3. Kraft RA, et al
. Arterial spin-labeling in routine clinical practice, part 1: technique and artifacts. AJNR Am J Neuroradiol 2008;29:1228–34 doi:10.3174/ajnr.A1030 pmid:18372417
CrossRef PubMed
17.↵
1. Wolf RL,
2. Detre JA
. Clinical neuroimaging using arterial spin-labeled perfusion magnetic resonance imaging. Neurotherapeutics 2007;4:346–59 doi:10.1016/j.nurt.2007.04.005 pmid:17599701
CrossRef PubMed
18.↵
1. Petersen ET,
2. Lim T,
3. Golay X
. Model-free arterial spin labeling quantification approach for perfusion MRI. Magn Reson Med 2006;55:219–32 doi:10.1002/mrm.20784 pmid:16416430
CrossRef PubMed
19.↵
1. Hodel J,
2. Leclerc X,
3. Kalsoum E, et al
. Intracranial arteriovenous shunting: detection with arterial spin-labeling and susceptibility-weighted imaging combined. AJNR Am J Neuroradiol 2017;38:71–76 doi:10.3174/ajnr.A4961 pmid:27789452
Abstract/FREE Full Text
20.↵
1. Lindner T,
2. Bolar DS,
3. Achten E, et al
; on behalf of the ISMRM Perfusion Study Group. Current state and guidance on arterial spin labeling perfusion MRI in clinical neuroimaging. Magn Reson Med 2023;89:2024–47 doi:10.1002/mrm.29572 pmid:36695294
CrossRef PubMed
21.↵
1. Berg J,
2. Porteous M,
3. Reinhardt D, et al
. Hereditary haemorrhagic telangiectasia: a questionnaire based study to delineate the different phenotypes caused by endoglin and ALK1 mutations. J Med Genet 2003;40:585–90 doi:10.1136/jmg.40.8.585 pmid:12920067
Abstract/FREE Full Text
22.↵
1. Plauchu H,
2. de Chadarévian JP,
3. Bideau A, et al
. Age-related clinical profile of hereditary hemorrhagic telangiectasia in an epidemiologically recruited population. Am J Med Genet 1989;32:291–97 doi:10.1002/ajmg.1320320302 pmid:2729347
CrossRef PubMed
23.↵
1. Porteous ME,
2. Burn J,
3. Proctor SJ
. Hereditary haemorrhagic telangiectasia: a clinical analysis. J Med Genet 1992;29:527–30 doi:10.1136/jmg.29.8.527 pmid:1518020
Abstract/FREE Full Text
24.↵
1. Le TT,
2. Fischbein NJ,
3. André JB, et al
. Identification of venous signal on arterial spin labeling improves diagnosis of dural arteriovenous fistulas and small arteriovenous malformations. AJNR Am J Neuroradiol 2012;33:61–68 doi:10.3174/ajnr.A2761 pmid:22158927
Abstract/FREE Full Text
25.↵
1. Mayercik V,
2. Taiwo R,
3. Marks M, et al
. O-023 Arterial spin labeling (ASL) MRI assists in identification of cerebral micro-arteriovenous malformations. J Neurointerv Surg 2021;13:A16
Abstract/FREE Full Text
26.↵
1. Grade M,
2. Hernandez Tamames JA,
3. Pizzini FB, et al
. A neuroradiologist’s guide to arterial spin labeling MRI in clinical practice. Neuroradiology 2015;57:1181–202 doi:10.1007/s00234-015-1571-z pmid:26351201
CrossRef PubMed
27.↵
1. Shimoda Y,
2. Osanai T,
3. Nakayama N, et al
. De novo arteriovenous malformation in a patient with hereditary hemorrhagic telangiectasia. J Neurosurg Pediatr 2016;17:330–35 doi:10.3171/2015.7.PEDS15245 pmid:26613274
CrossRef PubMed
28.↵
1. Alsop DC,
2. Detre JA,
3. Golay X, et al
. Recommended implementation of arterial spin-labeled perfusion MRI for clinical applications: a consensus of the ISMRM Perfusion Study Group and the European Consortium for ASL in Dementia. Magn Reson Med 2015;73:102–16 doi:10.1002/mrm.25197 pmid:24715426
CrossRef PubMed

Received January 22, 2024.
Accepted after revision March 7, 2024.
